Introduction

Nmap is a tool used for network mapping and it is one of the most popular ethical hacking tools in the market. Nmap is used to discover free networks around you. Network administrators find Nmap very useful as they always need to map their networks.

Hackers also started using Nmap for auditing networks and other purposes.

In this guide, we are going to look at What Nmap is, Nmap commands, and some more useful information about Nmap.

What is Nmap?

Nmap is a short form of Network Mapper and it’s an open-source tool that is used for mapping networks, auditing and security scanning of the networks. The reason behind its development is to quickly find large networks at a specific location. For the discovery of networks, the raw IP packets are used by Nmap. The most common use of Nmap is for security audits of networks.

As we see the rise in IoT devices and therefore, the networks are getting more complex for the companies using IoT devices. In this situation, Nmap comes into view where it can be used for auditing the network traffic between web servers of the organisation and the IoT devices.

Why learn about Nmap?

There can be various reasons to learn about Nmap. However, some of them include the following:

• It allows you to quickly find the networks and the devices on a specific network.
• Nmap is useful to find out which services are running on a system that includes all the web services and DNS servers.
• You can also find information about the operating system running on devices on a network.
• The GUI of Nmap is Zenmap which you can use to see the mappings of a network to use it for reporting and to enhance its usage.
• You can easily find out unauthorized services on your network.
• Nmap helps you to find the devices with open ports and you can look at them to enhance their security.

Nmap Command Examples in Linux and Unix

The port scanning is restricted and may result in an unethical practice from some jurisdictions’ point of view. Therefore, the Unix Lab setup can be done as follows:

In the above diagram, the Lab is set up in this way where,

• Server (1) is powered by an Operating system such as Win/macOS or Linux that will work as an unpatched server.
• Wks01 shows your operating system used for scanning the local networks using Nmap.
• Server (2) works the same as the server(1) where it is also powered by the operating system but the difference is that it is a fully patched server integrated with a firewall.
• All three systems such as Server(1), wks01 or the operating system, and server(2) are connected via a network switch.

                                                           Check out this Linux Tutorial

Features of Nmap

There are several features of Nmap that include the following:

• OS Detection: OS scanning can be done in Nmap that detects the OS, version of the OS, and other details about it.
• Service Detection: The several service probs found in the Nmap-services-probe-file are used to get the responses from network services and their applications.
• Host discovery: This method is used by network hosts to gather data about other hosts in the network by the use of TCP and UDP protocols.
• Target Specification: The target specification feature can be used to specify a Target IP address that you want to scan in Nmap.
• IPv6 Support: IPv6 means Internet Protocol version 6 and it can be used in Nmap for scanning the network. As IPv6 is capable of scanning larger addresses than IPv4, it makes scanning through CIDR-style scanning ranges that make it idle for scanning larger addresses.
• NSE Functionality: NSE stands for Nmap Scripting Engine and it comes in Nmap functionality that you can use for host discovery, network scanning, and target specification.
• TLS/SSL scanning: The TLS deployment problems can be analyzed fastly with the help of Nmap.

Nmap Commands

Here is the list of Nmap Commands

1. Scan a Range of IP Address
2. Port Scanning
3. Ping Scan Using Nmap
4. Saving the Nmap Scan Output to a File
5. Most Popular Ports Scanning
6. Display Open Ports:
7. Exclude Host/ IP Addresses for the Scan
8. Service Version Detection

   1. Scan a Range of IP Address: To scan a range of IP addresses, the Nmap command is as follows:

nmap 192.168.1.1-24

• 2. Port Scanning: There are multiple commands in Nmap for scanning ports such as:

To scan TCP port 80, the following Nmap command can be used:

nmap -p T:80 192.168.1.1

To scan UDP port 53:

nmap -p U:53 192.168.1.1

To scan the range of ports:

nmap -p 80-160 192.168.1.1

We can also combine all these commands to scan multiple ports:

nmap -p U:53, 112, 135, T:80, 8080 192.168.1.1

• 3. Ping Scan Using Nmap: It can be used for host discovery and the following command can be used:

nmap -sP 192.168.1.1/20

• 4. Saving the Nmap Scan Output to a File: The syntax for the command to save the Nmap output to a text file is as follows:

nmap 192.168.1.1 > op.txt

nmap -oN /temp/files/output/ 192.168.1.1

nmap -oN op.txt 192.168.1.1

• 5. Most Popular Ports Scanning: The most popular TCP ports can be scanned using TCP SYN scan and the following command exists for this purpose:

nmap -sS 192.168.1.1

• the above command is used for stealthy scan

For OS fingerprinting, the following command can be used:

nmap -sT 192.168.1.1

• 6. Display Open Ports: The command for displaying open ports on the network is as follows:

nmap –open 192.168.1.1

nmap –open server2.gl.biz

nmap –open 192.168.0.1

• 7. Exclude Host/ IP Addresses for the Scan: In order to exclude the hosts from the Nmap scan, you can use the following Nmap commands:

If you are scanning a number of hosts/networks, then you can exclude hosts/IPs from a scan by using:

nmap 192.168.1.1-24 –exclude 192.168.1.4

or

nmap 192. 168.1.1-24 –exclude 192.168.1.3, 192.168.1.7

for excluding more than one host.

• 8. Service Version Detection: The service version can be detected for IPv4 script with the help of Nmap by using any of the following commands:

nmap -A 192.168.1.254

or

nmap -v -A 192.168.1.1

or

nmap -A -iL /user/temp/list.txt

NMAP Commands Cheat Sheet

The following is a Nmap Command CheatSheet that contains some useful Nmap Commands:

Nmap commands for Port Selection:

Nmap Commands for Target Selection:

These commands are used to perform default scans using Nmap and it scans 1000 TCP ports where host discovery will also take place.

Nmap commands for OS and Version Detection:

The above commands are used to determine the operating system running on a particular port of the network. The command that we discussed for aggressive services detection can be used for the services running on unusual ports of the network.

Nmap commands for different Output Formats:

The default output can also be saved by simple redirecting the file with the command: command>file. In the above command, oN is used to save the results and also monitors the terminal for scanning.

Nmap command for IP address info:

The command above can be used to get the details related to the IP address and owner of that IP address. This command uses WhoIS, GeoIP location lookups and ASN query.

Nmap commands to gather HTTP service information:

These commands used to get the details about HTTP service are very useful for larger networks as it identifies the HTTP services on the network and reports immediately results.

To get more information about NSE scripts:

There are several NSE scripts in nmap that can be used for a wide range of security testing in the network. These scripts are also helpful in the discovery of new networks. The -sV parameter used in the commands above is used as a service detection parameter.

Nmap commands for port scan types:

These commands are very useful to scan port types. The SYN scan requires some privileged access and it uses TCP connect scan for insufficient privileges. The -Pn in the above commands is used for the PING parameter.

Conclusion

Nmap is a powerful tool used for networking and security auditing of networks. Nmap is helpful for quickly finding useful information about the networks, ports, hosts, and operating systems. There are other settings of Nmap too that enhance its productivity. In this article, we discussed the features of Nmap and why it should be learned. Also, we saw its cheatsheet where we included some commonly used commands of Nmap. To expand your skills further, check out our free online courses on cybersecurity and more.
